Flint’s SmoothAir – Rack Cooling
Rack Mount DX Precision Cooling in KSA & UAE
High-Efficiency Precision Cooling for Small & Medium Data Centers
Flint’s SmoothAir Series rack precision cooling solutions are engineered with a high-energy efficiency design to minimize operating costs while ensuring reliable performance. Tailored for network closets, small server rooms, and edge spaces, SmoothAir is the ideal choice for organizations looking for compact, efficient, and intelligent cooling.
Cooling Configurations
Top Packaged Type
2.5–5.5kW (9U–12U)
- Top-mount packaged design, saving IT space.
- Easy installation, service, and shipping.
Rack Split Type
3.9–12.8kW (6U–12U)
- Standard rack mount structure.
- Compressor located in outdoor unit reduces noise.
- Front air outlet, flexible installation at different rack heights.
Bottom Packaged Type
3.5kW (8U)
- Air-cooled packaged unit, mounted at rack bottom.
- No risk of water leakage.
- Simple, hassle-free installation.
Energy Efficiency
- Industry-leading inverter compressor and EC fan deliver optimized performance.
- Maintains stable temperature, preventing cycling during low heat load.
- Seamless compatibility with standard rack sizes for efficient hot/cold aisle containment.
- Uses green refrigerant R410A, highly efficient with zero ozone depletion potential (ODP).
Intelligent Control System
- Advanced smart control with insightful sensor data and intelligent logic.
- Digital control for all major components, ensuring optimum performance.
- Historical data tracking: 1000+ alarm records, 7-day pressure & temperature curves.
- Smart monitoring with Web/SNMP/Modbus/BACnet/Email/Dry contact/IPv6.
- Flexible teamwork functions: Master/Slave, Master Control, and Force Working modes.
- Built-in web server for desktop & mobile monitoring and control.
Condensate Evaporation System (Packaged Type Only)
- Integrated system evaporates condensate into steam, discharged via condenser fan.
- Prevents dripping inside and outside the unit, ensuring safer operation.
Searching for One-Stop Cooling Solutions for Your MDC?
Contact Us Now to discuss Flint SmoothAir Rack Mount DX Precision Cooling Solutions in KSA & UAE.
Key Components
Inverter Compressor
- Precise temperature control by adjusting output per heat load.
- Lower energy costs and extended compressor lifespan.
- Green refrigerant R410A with no ODP effect.
- Adjustable capacity from 30%–100%.
EC Fans
- High-reliability, best-in-class design.
- Highest efficiency with 0%–100% speed adjustment.
- Direct drive system – no belts, easy servicing.
- High static pressure capability for special applications.
Electronic Expansion Valve (EEV)
- Automatically modulates refrigerant flow to system requirements.
- Higher efficiency (COP) during low-temp conditions vs. TEV systems.
- Optimized refrigerant flow at compressor startup for maximum reliability.
